Worthington® VTE Reciprocating Pump

The VTE Reciprocating Pump is a vertical triplex positive displacement reciprocating pump with very high efficiency and is offered in a wide range of hydraulic, mechanical, and material options.

Worthington VTE Reciprocating Pump for Versatile Positive Displacement Applications

Benefits

1. Monoblock liquid ends are suitable for typical industrial services and oil and gas.
2. Proper concentricity within stuffing compartments is guaranteed by self-aligning plungers.
3. A wide variety of valve designs are available to accommodate all liquid types.
4. Allowing for more intricate sealing and piping arrangements, stuffing compartments are positioned outboard of the cylinder.
5. Stuffing boxes are individually affixed to the liquid cylinder to facilitate maintenance.
6. The power frame is completely enclosed, impervious to dust and oil, thereby preventing atmospheric contamination.
7. The load bearing area is maximised and attrition is reduced by cylindrical crossheads and guides, thereby minimising the need for replacement.
8. Lubrication systems that operate at full pressure to guarantee the protection and seamless operation of all bearing areas

Configuration

• Standard Design
• High Suction Pressure Design
• High Liquid Temperature Design
• Slurry Design

Specification

• Flows to 175 m³/h (772 gpm)
• Pressures to 431 bar (6250 psi)
• Temperatures from -40°C (-40°F) to 360°C (680°F)

Size Range: From 140 mm (5.50″) to 178 mm (7.00″) stroke, with 15.85 mm (0.625) to 146.05 mm (5.75″) diameter plungers, with power ratings of 192 kW to 633 kW.

Related Industries

• Power
  • Nuclear
• Chemicals
  • Basic (Organic & Inorganic)
  • Specialty (Fine & Consumer)
  • Pharmaceutical
• Water
  • Water Management
  • Wastewater
• Oil & Gas
  • Upstream Exploration & Production
  • Midstream Transportation
  • Downstream Processing
• General Industries
  • Steel & Primary Metals
  • Corn Wet Milling & Ethanol
  • Other Industries
• Mining

The Worthington VTE Reciprocating Pump is a dependable option for optimising your pumping systems. Contact us today to investigate customised solutions for your industry.
