Gamajet portable restroom cleaning system with 360-degree rotary jet head for hands-free cleaning of portable toilets

PortableRestroomHeader

Hands-Free, 100% Cleaning of Any Portable Restroom

Fast and Efficient Porta Potty Cleaning Portable restroom cleaning doesn’t get any easier than this. Gamajet’s all-in-one Portable Restroom Cleaning System has helped make one of the worlds dirtiest jobs simpler and faster, drastically lowering costs of water and reducing man-hours. With the Portable Restroom Cleaning System, you can clean any porta-potty in less than 10 minutes without brushing or spraying. The system has a custom made stand for cleaning the cabin with the door closed as well as a seat cover for cleaning in the holding tank with fitted suction pipes to allow for draining while cleaning.

Applying impingement cleaning to the portable restroom industry has saved companies thousands of dollars. The powerful rotating jets of water projected from the Gamajet IX in a 360 degree pattern quickly cleans the unit interior and holding tank, in a fast and efficient manner using less time and water than other methods. Even tip-overs are a breeze to clean using a Gamajet IX Cleaning System.

BenefitsTechnicalDownload Datasheet

Gamajet Portable Restroom Cleaning System with Jet Technology Application

  • Fast: Clean any portapotty in less than 8 minutes.
  • Hands-Free: No back splashing or scrubbing
  • Eliminate Odor: Clean the entire holding tank including the top.
  • Perfect for Tip-Overs

Gamajet Portable Restroom Cleaning System with Jet Technology  Technical Specs

  1. Components:
    1. Gamajet IX tank cleaning machine
    2. Custom designed splash guard for mounting the Gamajet in the holding tank
    3. Custom stand for placing Gamajet in the cabin
    4. Suction pipe and hose for draining with a 2” (50mm) adapter
  2. Operating Range
    1. Pressure: 500+ psi (35 bar)
  3. Temperature
    1.  32° to 180°F (0° to 82°C)
    2. Flow: 3.5-6 gpm (13-33 lpm) Typically 4 gpm (18 lpm)
    3. Wash Cycle Time: 2-4 minutes
    4. Impact: 1-2lbs (0.50-1kg)
  4. Overall Dimensions
    1. 22”x14”x19”H (560x355x480 mm)
    2. Weight: Approx. 60 lbs (27 kg)
  5. Features
    1. Connections
    2. Standard 3/8” (9.5mm) quick connects
  6. Optional
    1. Detergent Injector (Venturi pump)
    2. Gamajet KP Portable Gas Fired Pressure Washer
  7. Pump/Motor
    1. 5 HP Honda GC gas fired engine
    2. 4 gpm (18 lpm), 1500 psi (100 bar) max general pump
    3. Thermal pump protector
    4. Light-weight mounting frame
    5. Insulated trigger gun with stainless steel wand
    6. 25’ (7.5 m) of high pressure hose

How it Works:

Gamajets rotary impingement tank cleaning technology ensures the entire holding tank and cabin is cleaned. The power of the Gamajet IX will blast off any residue, especially the built up waste in holding tanks, allowing for less deodorants and chemicals.

Suction out bulk waste in holding tank. Connect your hoses and water supply to pressure washer. Connect hose to Gamajet splash guard. Connect Gamajet onto splash guard and place into holding tank. Use Gamajet adaptor to reduce 2” hose to Gamajet suction pipe and place in hole of splash guard. Turn on pressure washer and suction pump (to ensure holding tank does not fill). Allow Gamajet to clean for 4 minutes. Turn off pumps and connect hose from pressure washer to custom Gamajet stand, as well as the Gamajet IX. Place stand in cabin, remove toilet paper, and close door. (Door will not completely close due to hose). Let the Gamajet run for 4 minutes, water will run out the bottom. Cleaning is now complete.   Cleaning time can be reduced based on the level dirtiness.

PortaPottySystem

Manual scrubbing takes time and effort. The Gamajet system cleans portable restrooms in minutes with 360-degree impact. Reach out to us for the full setup.
