Byron Jackson SUBM submersible pump with oil-filled motor for deep well and vertical pumping needs
IntroductionFeaturesDocumentation

Byron Jackson SUBM submersible pump with oil-filled motor for deep well and vertical pumping needsSUBM Submersible Pump with Oil-Filled Motor

The Byron Jackson SUBM pump, developed for use in deep wells, is powered by submersible motors that are directly linked and loaded with oil. Continuous operation design possibilities include single and multistage configurations. Carefully selecting the hydraulics, materials and options to deliver the best value for the required applications.













Byron Jackson SUBM submersible pump with oil-filled motor for efficient deep well and vertical applications

The pumps are ruggedly constructed to ensure long service life in a variety of usage and operating conditions.

Related Industries

  • Power
  • Water
    • Water Management
    • Agriculture & Irrigation
    • Flood Control System
    • Desalination
  • Oil & Gas
    • Midstream Transportation
    • Downstream Processing
  • General Industries

Benefit

  • Radial, half-axial and axial flow hydraulics
  • Heavy duty axial motor bearings
  • Materials from cast iron to SuperDuplex
  • Bowl and impeller wear ring configurations
  • Winding insulation materials and winding layouts
  • Cable qualities and cable configurations
  • Motor filling fluid temperature control
  • Accessories (shrouds, control equipment, installation accessories, frequency converters, cables, non return valves, adapters, etc.)

Specification

  • Flows to 4500 m³/h (19800 gpm)
  • Heads to 800 m (2625 ft)
  • Motor sizes to 1650 kW (2200 hp)

Size Range:

  • Pump sizes from 150 mm (6 in) to 1375 mm (55 in), motor sizes from 200 mm (8 in) to 533 mm (21 in)
  • Motor power up to 1650 kW (2200 HP) 2 – 8-pole design, 50 & 60 Hz
  • Voltage up to 6600 V

Configuration

  1. Specifications for offshore and deep wells The gold standard for deep and offshore well designs.
  2. Motor designs are optimized for operation in high temperature conditions.
  3. Installation in hydrocarbon storage caverns necessitates a one-of-a-kind, explosion-proof design.

Byron Jackson SUBM Submersible Pumps and OIL Oil-Filled Motors Brochure

Byron Jackson Single Mechanical Seal Submersible Manual Instructions (IOM)

Designed for tough challenges, the SUBM pump is ready for your applications. Contact us to learn more.
