Rotary jet head (Sanitary)

Designed for hygienic, biotechnology and pharmaceutical applications, Toftejorg Rotary jet head tank-cleaning devices from Alfa Laval provide exceptional cleanability, better end-product quality, greater overall output and reduced operating costs.

Green Pepper

GPH is an open impeller centrifugal pump, manufactured from stainless steel AISI 316L. With excellent electro polished surfaces, high finish and mechanical strength, the GPH range meet the demands from a variety if today's industries. After all, GPH is still available at a very appealing price level.

Blagdon Hygienic Pump

B15 Hygienic Pump - Maximum Delivery: 70 ltrs/min (20 gal/min), Max. Working Pressure: 8.6 bar (125 PSI)

B25 Hygienic Pump - Maximum Delivery: 136 ltrs/min (36 gal/min), Max. Working Pressure: 8.6 bar (125 PSI)

B50 Hygienic Pump - Maximum Delivery: 500 ltrs/min (132 gal/min), Max. Working Pressure: 8.6 bar (125 PSI)

Blagdon FDA-Approved Pump

B15 FDA Pump - Maximum Delivery: 58 ltrs/min (12.7 gal/min), Max. Working Pressure: 8.6 bar (125 PSI)

B25 FDA Pump - Maximum Delivery: 180 ltrs/min (40 gal/min), Max. Working Pressure: 8.6 bar (125 PSI)

B40 FDA Pump - Maximum Delivery: 320 ltrs/min (70 gal/min), Max. Working Pressure: 8.6 bar (125 PSI)

B50 FDA Pump - Maximum Delivery: 500 ltrs/min (110 gal/min), Max. Working Pressure: 8.6 bar (125 PSI)

Seat Valves

LKAP: Compact and straightforward, LKAP seat valves are reliable air-operated shut-off valves widely used for small flow rates and for dosing applications in the dairy, food and beverage industries.

Radial Diaphragm Valve UltraPure: This compact, maintenance friendly radial diaphragm valve with its double-sealing system provides true aseptic conditions for sterile applications where leakage, deadlegs or cross-contamination is unacceptable.

Unique 7000 (US): Tri-Clover Unique 7000 single seat valves combine proven technology and innovative features, with a one-piece body moulded from a single stainless steel disc.

Unique single seat valve: Ideal for uninterrupted production in a broad range of hygiene-critical applications, Unique single seat valves are pneumatic seat valves used to shut off or change product flow.

Regulating Valves

Constant pressure modulating valves: CPM valves maintain uniform inlet or outlet pressure in hygienic process lines for the dairy, food and beverage industries. These regulating valves provide accurate pressure control, safe and reliable performance and excellent cleanability.

SPC-2 regulating valves: SPC-2 regulating valves provide accurate control of pressure, flow, temperature and liquid levels in tanks and stainless steel pipe systems used for hygienic processes in the dairy, food and beverage, and biopharm industries.

Mixproof Valves

SMP Mixproof Valve: Ideal for handling sanitary process flows through matrix piping systems, SMP mixproof valves are standardized, cost-effective alternatives to Unique mixproof valves.

Unique mixproof CP-3 valve (US) : The Alfa Laval Unique mixproof CP-3 valve is a highly efficient light-weight, reduced vent mixproof valve – maximizing floor space while greatly minimizing CIP consumption, and virtually eliminating downtime. Ideal for all types of hygienic processes.

Unique mixproof valve: Unique mixproof valves enable the simultaneous flow of two different products or fluids through the same valve without risk of cross-contamination. This enhances plant flexibility and efficiency of the dairy, food and beverage, and biopharm industries.

Unique PMO mixproof valves (US): Alfa Laval PMO mixproof valve technology allows CIP solution to clean one valve seat while product runs in the opposite housing – virtually eliminating CIP downtime so processors can increase production while maximizing floor space and resources.

Miscellaneous Valves

AS-H Coplastix flow control products - Products include slide gates, stop gates and logs, and flap valves

Ball valve UltraPure - The valve consists of a 316L (CF3M9) steel valve body, PTFE valve seats..

Shutter valve- valve consist of a rigid body with an internal cylindrical bore and 2 or 3 ports for pipe connection...

LKUV-2 air-relief valves - consists of an upper valve body, lower valve body with welding stub, seal ring and polypropylene ball...

Sanitary ball valves - consists of a valve body, two flanges, PTFE valve seats, ball, stem unit and either a handle for manual operation...

SCANDI BREW® Sampling - asy and quick to take samples from both indoor and outdoor beer tanks avoiding the traditional catwalks ...

Unique Diaphragm Valve - Premium UltraPure - onsists of a valve body, diaphragm, handle or actuator, and indication and control units...

Unique sampling valve - onsist of a valve body, an actuator and membrane seal...

Diaphragm Valves

Radial Diaphragm Valve UltraPure - its double-sealing system provides true aseptic conditions for sterile applications where leakage, deadlegs or cross-contamination is unacceptable.

Unique Diaphragm Valve - Premium UltraPure - rovides a higher flow rate and lower pressure drop than traditional diaphragm valves.

Unique Diaphragm Valve UltraPure - meets the requirements of most sterile and ultra-hygienic processes.

Check Valves

LKC-2 non-return valves - consists of an upper valve body, lower valve body, valve plug, seal ring, and guide disc.

LKC UltraPure non-return valve - is a non-return valve preventing reverse flow in a system. The UltraPure execution is designed and documented to meet the demand in industries like BioPharm and Personal Care.
